Silver Coated Glass is a precision glass substrate engineered with a high-purity silver thin film for semiconductor and optical processing environments. Stanford Electronics produces the silver layer using controlled physical vapor deposition, supported by systematic thickness monitoring and surface inspections. Optical analysis and surface characterization are applied throughout production to maintain coating consistency and dimensional accuracy, ensuring the substrate meets defined tolerances for semiconductor raw material use.
Silver Coated Glass consists of a borosilicate glass base coated with a uniformly deposited silver film. The controlled deposition process produces a smooth, reflective surface with minimal thickness variation. This structure supports accurate light reflection and stable electrical behavior, making the substrate suitable for semiconductor photolithography, optical monitoring, and precision processing applications.
| Parameter | Value |
|---|---|
| Material | Silver, Borosilicate |
| Purity | Ag: ≥99.99% |
| Form | Substrate |
| Dimensions | 22 × 22 × 0.2 mm; Ø15 × 0.15 mm; or customized |
| Adhesion Layer | Titanium (20 / 50 / 75 Å) |
| Ag Thickness | 100 / 500 / 1000 / 5000 Å |
| Coating Area | Single size (or customized) |
The above product information is based on theoretical data and is for reference only. Actual specifications may vary.
Semiconductor Manufacturing
Used as a reflective surface in photolithography systems to improve exposure uniformity and pattern accuracy.
Applied in process monitoring components where stable optical response is required.
Industrial Electronics and Optics
Utilized in optical sensors and inspection equipment to deliver consistent signal reflection.
Integrated into quality control systems to enhance measurement precision through reliable reflective performance.
Silver Coated Glass substrates are sealed in anti-static, moisture-resistant pouches and placed in foam-lined protective containers to reduce mechanical stress and contamination. Storage and transport are conducted under controlled environmental conditions to preserve coating integrity. Customized packaging and labeling options are available upon request.
Silver-coated glass substrates are widely used in semiconductor and optical technologies due to silver’s high reflectivity and electrical conductivity. Ongoing advances in thin film deposition and surface analysis continue to improve coating consistency and durability, enabling reliable performance in precision manufacturing and research environments.
|
Parameter |
Value |
|
Material |
Silver, Borosilicate |
|
Purity |
Ag: ≥99.99% |
|
Form |
Substrate |
|
Dimensions |
22*22*0.2 mm, Dia.: 15 mm * 0.15 mm, or customized |
|
Adhesion Layer |
Titanium (20/50/75 Å) |
|
Ag Thickness |
100/500/1000/5000 Å |
|
Coating Area |
Single Size (or customized) |
*The above product information is based on theoretical data and is for reference only. Actual specifications may vary.
